Vented Loop

Vented Loop

$53.43
$53.43 $86.17
ColorBlack
Size

Installed in toilet systems where the toilet or holding tank is below waterline or near waterline, to prevent sea water from siphoning through the toilet system, potentially swamping the vessel. Inlet and outlet plumbing is looped well above waterline and the vented loop is installed at the top of the loop, preventing siphoning. When installing ensure the vented loop will remain above water line when boat is fully loaded and/ or heeled.

Other Details:

BLA Code Hose Size
mm in		 Height
mm		 Width
mm		 Depth
mm		 Mount Holes
mm
139090 19 ¾ 75 96 25 6 r/h
139092 25 1½ 100 150 43 6 r/h
139096 38 1½ 130 200 55 6 r/h
