Flexible Engine Mounting Type HY
NA / Max Load: 230kg
$72.95
Sale price
$72.95
Regular price
$113.99
Skip to product information
Flexible Engine Mounting Type HY
$72.95
Sale price
$72.95
Regular price
$113.99
The VETUS Type HY flexible engine mounting is engineered for heavy-weight marine diesel engines with 4 or more cylinders. Its low vertical stiffness combined with high longitudinal stiffness makes it ideal for engines in the 30–125 kW (40–170 hp) power range.
Specifications
| Type | Stiffness: Vertical | Stiffness: Athwartships | Stiffness: Fore & Aft | Min. Load (kg) | Min. Compression (mm) | Max. Load (kg) | Max. Compression (mm) | Hardness (Shore °) |
|---|---|---|---|---|---|---|---|---|
| HY100 | 1 | 1.2 | 3.5 | 40 | 2 | 100 | 5 | 40 |
| HY150 | 1 | 1.2 | 3.5 | 60 | 2 | 150 | 5 | 50 |
| HY230 | 1 | 1.2 | 3.5 | 92 | 2 | 230 | 5 | 60 |
